| Model | PFH610V | PFH610V-H | PFH610V-H-POE | PFH610V-IR | PFH610V-IR-POE | |
| General | ||||||
|
Inside Dimension
(LxWxH)
|
255x90x83mm
(10.04”x3.54”x3.27”)
|
255x90x70.5mm(10.04”x3.54”x2.78”)
215x90x83mm(8.46”x3.54”x3.27”)
|
||||
| Window Dimension | ɸ60mm(ɸ2.36”) | |||||
| Operating Temperature | Set |
-30ºC ~+60ºC
(-22℉~+140℉)
|
-40ºC ~+60ºC(-40℉~+140℉) | |||
| Heater | N/A | ON: 5±5 ºC /OFF: 15±5 ºC |
ON: <+5ºC(+41℉)
/OFF: +5ºC(+41℉)
|
|||
| Cooler | N/A |
ON: 37±5 ºC /OFF: 20±5 ºC
ON: 5±5 ºC /OFF: 15±5 ºC
|
ON: 37±1ºC(98.6±33.8℉)
/OFF: 20±1ºC(68±33.8℉)
|
|||
| IR Distance | N/A | 0~100m(0~328.08ft) | ||||
| RS485 Control | N/A | Yes, use RS485 to control IR light | ||||
| Power Supply | DC12V, AC24V | AC24V/3A, DC24V | POE+ |
AC24V/5A,
DC24V
|
POE+ | |
|
Power Consumption
(without camera)
|
N/A | 45W | 25.5W | 67W | 25W | |
| Environmental | ||||||
| Operating Temperature |
-30ºC ~60ºC
(-22℉~+140℉)
|
-40ºC ~60ºC
(-40℉~+140℉)
|
||||
| Humidity | <90% RH | |||||
| Ingress Protection | IP67 | |||||
| Vandal Resistance | IK10 | |||||
| Corrosion Protection | N/A | |||||
| Construction | ||||||
| Material | Aluminum(case)&PC(others) | |||||
| Dimension(LxWxH) | 404mmx164mmx132mm(15.91”x6.46”x5.2”) | |||||
| Weight | 2.5kg(5.51lb) | 2.7kg(5.95lb) | 3.0kg(6.61lb) | 3.0kg(6.61lb) | 3.2kg(7.05lb) | |
| Others | ||||||
| Certification | CE, FCC, ICES | CE, FCC, UL, EAC, ICES | CE, FCC | CE, FCC, UL, EAC, ICES | CE, FCC, ICES | |
| Applicable Model | Please see “Accessory Selection” | |||||
