| General parameter | ||
| Product name | 12 ports Gigabit Industrial POE Switch | |
| Model | HR600-AFG-822S | |
| Connector Type | 8*gigabit POE ports+2*gigabit uplink ports+2*Gigabit SFP ports(Combo) | |
| Network Protocols | IEEE802.3
IEEE802.3i IEEE802.3u IEEE802.3ab IEEE802.3z |
|
| POE Parameters | POE Standard: IEEE802.3at (30W) and IEEE802.3af (15.4w) | |
| Each port Max：15.4 W (IEEE 802.3af)
Each port Max：30 W (IEEE 802.3at) |
||
| POE compatibility：IEEE 802.3af/at adaptive | ||
| POE port output： DC 52V | ||
| POE power supply core：1/2+ ; 3/6- | ||
| Network Media | 10BASE-T: Cat5 UTP(≤100 m)
100BASE-TX: Cat5 or more UTP(≤100 m) 1000BASE-TX: Cat5 or more UTP(≤100 m) |
|
| Fiber Media | Multi-mode：850nm，1310nm transmission distance：550m/2Km
Single-mode：1310nm，1550nm transmission distance：20/40/60/80/100/120Km |
|
| LED indicator | PWR | Lighting：Powered
Un-Light：No Power |
| Port Yellow | Lighting：POE Powered
Un-Light：No Power |
|
| Port Green | Slow flash：Connecting
Quick flash：Data Transmit Un-light：Disconnect |
|
| G9，G10 | Lighting：SFP/Uplink connecting
Un-Light：SFP/Uplink unconnect Quick flash：Data Transmit |
|
| Power Supply | Power input: DC 48～55V
power supply wiring: 6 PIN terminal block（V1+ V1- GND V2+ V2-） |
|
| Working Environment | Operating Temperature: -40～75℃
Storage Temperature: -40～85℃ Humidity: 5%~95 %( non-condensing) |
|
| Industry Standard | EMI: FCC Part 15, CISPR (EN55032) class A
EMS: EN61000-4-2 (ESD) EN61000-4-4 (EFT) EN61000-4-5 (Surge) |
|
| Mechanical Structure | Shell protect grade: IP40
Installation: DIN rail N.W：0.8 KG G.W:1.1 KG(without power supply) Product Dimension (L×W×H)： 166mm×125mm×60 mm Package Dimension(L×W×H) ： 250mm×210mm×88mm Carton Box Dimension(L×W×H)：608mm× 500 mm× 435mm Packing Quantity：28 (PCS) |
|
| Package Contents | 1. Industrial Switch： 1 unit
2. User Guide：1unit 1. Certificate warranty card：1unit |
|
| Certification | CE、CCC、FCC、ROSH | |
| Warranty | 5 years | |
| Hardware parameter | ||
| Bandwidth | 20Gbps | |
| Cache | 2M | |
| Chipset | 88E6390 + 88E1112 | |
| Package Forwarding Rate | 14.88Mpps | |
| MAC address | 16K | |
| Forwarding mode | Store-and-forward | |
