سوئیچ مدیریتی PoE اچ ار یو ای HRUI HR901-AFGM-82NS-150
HRUI HR901-AFGM-82NS-150 Managed Gigabit 10 Ports POE Switch
شرح امکانات:
- 8 پورت 10/100/1000M PoE و 2 پورت SFP گیگ و یک پورت کنسول
- سوئیچ مدیریتی گیگ PoE
- خروجی 150 وات
- 24 ماه وارانتی بی قید و شرط (12 ماه گارانتی تعویض + 12 ماه گارانتی تعمیر)
General Performance Indicator |
|||
Product Name |
10 Port Gigabit Managed PoE Switch |
||
Product Model |
HR-AFGM-82NS |
||
Interface |
8*10/100/1000M PoE Ports + 2*Gigabit SFP Ports + 1*Console Port |
||
Network Protocols |
IEEE802.3 IEEE802.3u IEEE802.3ab IEEE802.3x IEEE802.3z |
||
PoE Parameters |
PoE Standard: IEEE802.3at (30W) and IEEE802.3af (15.4w) |
||
PoE compatibility: IEEE 802.3af/at adaptive |
|||
PoE port output: DC48-55V |
|||
Power Pin Assignment: Power over spare pairs 1/2(+) and 3/6 (-) |
|||
Port Lightning Protection |
General Mode 6KV, Differential Mode 4KV, ESD 15KV. |
||
Network Transmission Medium |
10BASE-T: Cat3, 4, 5 UTP (≤ 100 m) 100BASE-TX: UTP (≤100 m) above Cat5 1000BASE-TX: UTP (≤100 m) above Cat5 |
||
Optical |
MultiMode Fiber: 850nm, 1310nm, Transmission Distance: 550m/2Km Single-Mode Fiber: 1310nm, 1550nm, Transmission Distance: 20/40/60/80/100/120km |
||
DIP Definition |
VLAN: 1-8 ports are isolated from each other, and only connect Uplink with 9、10 Port; Default: 1-10 port is standard, all ports can communication; Extend: 7-8 port supports 250m link extension at a rate of 10M. |
||
Power Supply |
Input Voltage: AC100~-240V; Output: DC 52V2.3A Total power: 120W |
||
LED indicator |
|
POWER |
Lighting:Powered Un-Light:No Power |
SW |
Lighting: LVAN Un-Light: Default Flashing: Extend |
||
SYS |
Flashing: System Start-up Lighting: System Running |
||
9-10 |
Lighting: Link connection Flashing: Data transmission Un-Light: Link disconnect |
||
PoE/ACT (1-8 Port) |
Lighting:Powered Un-Light:No Power |
||
Link/ACT (1-8 Port) |
Lighting: Link connection Flashing: Data transmission Un-Light: Link disconnect |
||
Physical Dimension |
Product size (L×W×H): 270mm× 180mm× 45mm Package size (L × W × H): 312mm × 260mm × 84mm |
||
Working Environment |
Operating Temperature: -20℃ ~ 50℃; Storage Temperature: -40℃ ~ 85℃; Operating Humidity: Max 90%,non-condensing Storage Humidity: Max 95%, non-condensing Working Height: Max to 10,000 feet (3,000 meters) Storage Height: Max to 10,000 feet (3,000 meters) |
||
Package Contents |
1. Switch: 1 set 2. Instruction manual: 1 3. Certificate of conformity: 1 4. Warranty card: 1 5. Power Supply 1 6. A pair of hanging ears |
||
Certification |
CE, FCC, RoHs, 3C |
||
MTBF: |
100,000 hours |
||
Warranty |
2 years warranty |
||
Technical Indicators |
|||
Bandwidth |
20Gbps |
||
Packet Forwarding rate |
14.88Mpps |
||
Packet Buffer Memory |
4M |
||
Memory Capacity |
128MB |
||
Flash Capacity |
16MB |
||
Jumbo frame |
9.6Kbytes |
||
VLANs |
4096 |
||
MAC |
8K |
||
Forwarding Mode |
Store-And-Forward |
||
Layer 2 Software Function |
|||
Port Management |
Enable/Disable Port |
||
Speed、Duplex、MTU Setting |
|||
Flow-control |
|||
Port Information Check |
|||
Port Mirroring |
Supports both side-way port mirroring |
||
Port Speed Limit |
Supports port speed limit, speed limit granularity 32Kbps |
||
Port Isolation |
Support the downlink port isolation, and can communicate with the uplink port |
||
Storm Suppression |
Supports unknown unicast, multicast, unknown multicast, broadcast type storm suppression Storm suppression based on bandwidth regulation and storm filtering |
||
Link Aggregation |
Support static manual aggregation Support LACP dynamic aggregation |
||
VLAN |
Access |
||
Trunk |
|||
Hybrid |
|||
Support port, protocol, MAC-based VLAN partitioning |
|||
Support GVRP dynamic VLAN registration |
|||
Voice VLAN |
|||
MAC |
Support static addition, deletion |
||
MAC address learning limit |
|||
Support dynamic aging time setting |
|||
Spanning tree |
Support STP spanning tree protocol Supports RSTP Rapid Spanning Tree Protocol Supports MSTP Rapid Spanning Tree Protocol |
||
Multicast |
Support static addition, deletion IGMP-snooping |
||
Support MLD-Snooping |
|||
Support v1/2/3 dynamic multicast monitor |
|||
DDM |
Support SFP/SFP+DDM |
||
Extended Function |
|||
ACL |
Based on source MAC, destination MAC, protocol type, source IP, destination IP, L4 port |
||
Qos |
Based on 802.1p (COS) classification |
||
Based on DSCP classification |
|||
Classification based on source IP, destination IP, and port number |
|||
Support SP, WRR scheduling strategy |
|||
Support flow rate limit CAR |
|||
LLDP |
Support LLDP link discovery protocol |
||
User settings |
Add / delete users |
||
Log |
User login, operation, status, events |
||
Anti-attack |
DOS defense |
||
Support CPU protection and limits the rate of sending cpu packets |
|||
ARP binding (IP, MAC, PORT binding) |
|||
Certification |
Support 802.1x port authentication |
||
Support AAA certification |
|||
Network diagnosis |
Support ping、telnet、trace |
||
System Management |
Device reset, configuration save/restore, upgrade management, time setting, etc. |
||
Management function |
|||
CLI |
Support serial port command line management |
||
SSH |
Support SSHv1/2 remote management |
||
TELNET |
Support telnet remote management |
||
WEB |
Support Layer 2 settings, Layer 2 and Layer 3 monitor |
||
SNMP |
SNMP V1/V2/V3 |
||
Support trap:ColdStart、WarmStart、LinkDown、LinkUp |
|||
RMON |
Support RMON v1 |
||
PoE |
Support PoE configuration, PoE scheduling management,PoE watchdog 、 PoE port timing restart |
||
Other functions |
Support DHCP Snooping、Option82 |
||
Support Ring-Network Protection |
|||
Support dynamic ARP detection |
|||
Support TACACS+ certification |
|||
Support DNS certification |
|||
Support port security settings |
|||
Support MVR protocol |
|||
Support cable detection VCT function |
|||
Support UDLD protocol |
مشخصات سوئیچ مدیریتی PoE اچ ار یو ای HRUI HR901-AFGM-82NS-150
نوع سوئیچ | سوئیچ PoE |
قابلیت مدیریت | دارد |
توضیحات مدیریت | پشتیبانی از CLI (command line management) پشتیبانی از ریموت Telnet پشتیبانی از اینترفیس Web ریموت مدیریتی SNMP ریموت مدیریتی SSH ریموت مدیریتی RMON |
تعداد پورتها | 8 پورت 2 پورت SFP 1 پورت Console |
نوع پورت ها | RJ45 10/100/1000Mbps فیبر نوری گیگ |
ویژگی های پورت | پشتیبانی از PoE |
استانداردهای شبکه | IEEE 802.3u IEEE 802.3ab IEEE 802.3z IEEE 802.3x IEEE 802.3 IGMP Snooping DHCP Snooping |
پهنای باند | 20Gbps |
نرخ انتقال داده در واحد ثانیه | 14.88Mpps |
ظرفیت جدول مک آدرس | 8K |
استاندارد پورت PoE | IEEE802.3af/at |
قدرت خروجی هر پورت PoE | 15.4/30W |
میانگین زمان بین خرابی | 100,000 ساعت (حدود 11 سال) |
مسافت انتقال داده | 100 متر با کابل شبکه Cat.5 |
پشتیبانی از شرایط محیطی | منفی 20 تا مثبت 50 درجه سانتیگراد با رطوبت 90 درصد |
نشانگر LED | روشن / خاموش بودن قطع /وصل بودن پورت اترنت انتقال / عدم انتقال داده در پورت اترنت فعال بودن قابلیت PoE فعال / غیرفعال بودن پورت فیبر نوری |
منبع تغذیه | خروجی DC 52V 2.3A ورودی AC 100~240V |
گواهینامه ها | CE FCC CCC ROHS CE/LVD EN60950 |
سایر مشخصات | ظرفیت فلش 16 مگابایت جامبو فریم 9.6Kbytes مدیریت سیستم دارای قابلیت Watchdog Flow Control Port Mirroring Port speed limit Port isolation Storm suppression برای داده های دریافتی قابلیت Link aggregation قابلیت VLAN قابلیت Spanning Tree قابلیت ACL ویژگی QoS قابلیت LLDP قابلیت Anti-attack پشتیبانی از Full/Half-duplex پشتیبانی از Auto MDI/MDI-X مقاوم در برابر رعد و برق |
عنوان | گروه | اندازه | نوع فایل | دانلود |
---|---|---|---|---|
HR-AFGM-82NS Datesheet.pdf | [Datasheet] | 206KB | Download | |
AFGM82NS150 (1).png | [Images] | 4691KB | .png | Download |
AFGM82NS150 (2).png | [Images] | 4011KB | .png | Download |
AFGM82NS150 (3).png | [Images] | 4400KB | .png | Download |
